In a notable progression within the semiconductor industry this October, ROHM Semiconductor, a leading power device manufacturer in Japan, has announced a strategic move to further enhance its collaboration with TSMC (Taiwan Semiconductor Manufacturing Company) in the domain of Gallium Nitride (GaN) power semiconductorsThis collaboration entails that all of ROHM's GaN products will now be outsourced for production to TSMC, signifying a significant shift in their operational strategy.

Historically, ROHM depended primarily on its internal factories for manufacturing these devicesHowever, in recent years, the company has begun to delegate some of its products to TSMC for production—a detail that they had not made public until now

The latest development suggests that ROHM is transitioning towards a comprehensive partnership with TSMC, particularly focusing on the production of versatile 650V-rated products to cater to the surging demand within the marketThis strategy will not only help in scaling up their business but also enables them to leverage external resources effectively.

Industry analysts have pointed out that this move could potentially lower production costs for ROHM, as GaN materials, despite their superior performance characteristics, have been traditionally costlyShould this collaboration prove successful, it could instigate a significant reshaping of the market landscape, positioning the partnership between TSMC and ROHM as a pivotal milestone in the GaN industry, thereby accelerating advancements in technology and commercialization.

Additionally, this strategic move might indicate a shift in ROHM’s operational model from an Integrated Device Manufacturer (IDM) to a Fabless approach, highlighting the evolving dynamics within the semiconductor industry.

The Remarkable Properties and Wide Applications of GaN

The research and development of wide bandgap materials like GaN have evolved significantly over the years
